High-quality Image. Optimal Axial and Lateral resolution. Ideal for personal use, for intensive care units.
CONVEX, CARDIAC and LINEAR 128 ELEMENT COLOR DOPPLER |
Scanning Mode |
Convex |
Phased (Cardiac) |
Linear |
Image Enhancement |
0.1.2.3.4 |
Frequency |
3.5-5 MHz |
2.5/5 MHz |
|
Focus |
0.1.2.3 |
Depth |
90-160mm |
90/120/140/160mm |
|
Elements |
128 |
Cineplay |
100 / 200 / 500 / 1000 |
BTGC |
Yes |
Application |
Cardiac, Abdomen, Urology, Ginecology, Breast, Thyroid, Vascular |
Dynamic Range |
40 - 110 Db |
Measure |
B: Length, Area / Circumference, Angle, Trace, Distance.
GA (CRL, BPD, GS, FL, HC, AC), EFW (BPD, FL)
B / M: Heart Rate, Time, Distance,
B / PW: Velocity, Heart Rate, S / D, Depth |
Charge |
USB Cable or wireless charge. 2h |
Display mode |
B, B / M, Color doppler, PW doppler, Power doppler. |
Gain |
30 - 105 Db |
Power consumption |
10W (probe run) 2W (probe stop) |
Image gray scale |
256 level |
Bettery capacity |
Lithium Battery, 2800 mAh. Working time > 3h, Standby time > 12h, supporting working while charging. |
Image frame rate |
20 f / s |
Language |
Inglish, Italiian, Spanish, Potuaguese German, French, Chinese. |
Size |
125 - 70 - 20 mm |
Host |
IQS, ipad / iphon, Android, Windows. |
Weight |
120 g |
Image format |
GPG. AVL. MP4. DICOM |
Package |
Probe, Planchet, Software, Wireless charger, Cable, Aluminum Case |
Software controls |
GN (gain), D (depth), ENH (enhencement), DR (dynamic range), F (frequency), PRF, WF, Focus, Mode B, B/M, Color doppler, PW, Power doppler, Biopsy, Pade left / right, UP / Down, 8TGC |
Connection |
2,4G / 5G, WIFi, USB |
